DORA-U™

Description

The slip and low profile body design with precise light distributions perfect to replace discharge lamps from 75 to 1000W with great ROI.

Key Features
  • High efficiency with low operating costs.
  • Multiple light distributions to replace discharge lamps from 75W to 1000W.
  • High energy savings compared to systems with traditional HlD luminaires.
  • The slim and low profile body minimizes wind load.
  • High energy savings compared to systems with traditional HlD/HPS luminaires in high R0l.
  • Dimmable for even more energy savings.
  • Combine modular light engines in the light compartment for easy hassle-free maintenance and component hardware replacement.
  • Long life-span thanks to robust design and separated thermal management system of Light engine and power supply.
  • lP66 and Suitable for Wet Location.
Technical Specifications


DORA-U™

Power 40-300W
Voltage UL 90-305V/ UH 249-528V*
PF >0.95
THD <20%
L85 >150,000H/>50,000H
Operating Temperature -40F- 122F
Efficacy 150lm/W
ANSI CCT 2700K/3000K/3500K/4000K/5000K/5700K/6500K
Min CRI 70* or 80 or 85
IP Rating IP67
SPD  10KA* or 20KA
Dali Optional
1-10V Optional
Photocell  Optional
Smart Control Optional
Optic(IESNA) Type II, Type III, Type IV
Color Options  Grey/Black/Bronze/White


Spec Sheet

Spec Sheet
